light source: Osram371W
color temperature: 7000K±500K
Voltage: AC100~240V 50/60Hz
Rated power: 600W
Zoom range: 3°~45°
Illumination: 784000Lux(6M@3°)
Dimming: 0~100% linear dimming
Focusing: Electronic focusing, ultra-fine smoothing
Strobe: 1~25 times/second, random + pulse
Atomization: 0~100% soft light
Color wheel: 14 fixed colors + white light, half-color effect, two-way rotating rainbow.
Fixed gobo: 13+1 pattern.
Rotating gobos: 8 plug-in gobos + white circles, with pattern jitter and arbitrary positioning functions
Effect Wheel: 1 pc
Prism 1: 2 different prism elements can be inserted and rotated forward and backward.
Prism 2: 1 prism lens and 1 atomizing lens can be inserted, and forward and reverse rotation can be realized.
Prisms can be stacked, 16 prisms and 80 prisms can be stacked with 96 prism effects.
Operation mode: DMX mode, master-slave mode
Control protocol: DMX512
Channel mode: 24CH/17CH
Horizontal scanning: 540° (16 bit precision scanning)
Vertical scanning: 270° (16-bit precision scanning)
Degree of protection: IP20
Size: L350×W270×H600mm
WEIGHT: 18KG
Ambient temperature: -25°C~40°C
