Input voltage:AC100-240V,50/60Hz

Rated power:850W@220V

Light source: 600W LED module

LED life: 20,000 hours

Beam Aperture: 3°-45°fast motorized linear zoom

Pan: 540"(16 bit precision scanning)

Tilt: 270"(16 bit precision scanning)

Frost system:0-30hz

Dimming system:0-100% linear adjustment

Fixed color: 8 colors +open position+CMY+CTO

Fixed Gobos: 12 fixed gobos +Open

Rotating Gobo wheel:7plug in gobos +open（diameter 22.8mm, effective diameter 14mm、Thickness: 1.1mm）

Prisms: 6 Linear Prism+8 Prisms, each can be independently reverted.

Channel mode:25/35CHs

Control mode: DMX512, RDM, Auto Mode, master-slave

Protection rate:lP20

Power interface: Powercon in/out

Signal interface: three pin XLR (five pin XLR optional)

Working environment:-20-45degree

Product net weight:23.5KG

Product dimension: 380x274x700mm

Packing Dimension: 795x365x505mm

Packing Weight: 27.5kg



Accessories in package: Power Cable, Signal Cable, Safety Wire and Integrated Folding Clamps
